| The System I Water to Water Heat Exchanger is designed for use with existing building water systems. If your facility is equipped with a central building chilled water system, water quality, temperature instability, pressure and flow fluctuations are problems you may have to overcome to properly cool your instrumentation or equipment.
Our System Series of Water to Water Heat Exchangers uses the cooling of your building's central water system while eliminating all the problems associated with building water. Your water supply circulates through one side of the heat exchanger while the System pumps temperature controlled water out of a secondary circuit directly to your equipment. Your equipment will be protected from contaminants commonly associated with building water systems because you control the quality of the fluid that the System circulates.
Features:
- Easy to operate temperature control
- Large gauges for pressure and temperature readings
- Rugged pumps to ensure proper flow to your application
- Status relay for high temperature and low level conditions
- Water modulating valve conserves building water
Note: Cooling capacity is based on a 10C temperature differential between the cooling water supply and the cooling fluid flowing from the System to the instrument being cooled.
|
| Temperature Range : |
5°C to 35°C |
| Temperature Stability : |
+/-1.0 |
| Cooling Capacity : |
14,000 watts |
| Pump : |
PD-2 3gpm, 60 psi |
| Reservoir Volume : |
1 gallon |
| Power Requirements : |
115V, 60Hz,7 Amps |
| 50Hz Power Requirements : |
220-240V, 50Hz,3 Amps |
